DVL Series

Size

135"

Architecture

SMD

Resolution

Full HD, 1920 x 1080

Aspect Ratio

16:9

Pixel Pitch

1.2

Contrast Ratio

15000 : 1

Brightness (nits)

100-600 cd/m2

LED Lifespan (max hrs)

100,000hrs

Gray Scale (bit)

13+6bit

Refresh Rate (Hz)

3840

Viewing Angle (H-V°)

165/165

Power Supply

AC 100-240V 50/60Hz

Power Consumption (W)

483(Typ), 1460(Max)

Standby Power Consumption (W)

≤0.5

Speaker (W)

2 x 20

Wireless

WiFi 6, AP and STA modes, and WiFi 6 dual-band 2.4G/5G, Supports Bluetooth 5.3

Input

HDMI 2.0, HDMI 1.4x3, USB2.0, USB3.0x2, Type-C, POE, RJ45, 3.5mm Audio In

Output

HDMI 2.0, 3.5mm Audio Outx2, USB

Control

RS232

Operating System

Android 13.0, Windows OS (Optional)

Central Processing Unit (CPU)

Cortex-A76 x 4 + Cortex-A55 x 4

Random Access Memory (RAM)

8

Read Only Memory (ROM)

64

Installation Method

Wall mounting, Ceiling hanging, Mobile Stand

Cabinet Material

Die-casting Magnalium

Operating Temperature (C/F)

-10° - 40° / 14° - 104°

Operating Humidity (%)

10 - 80 RH No Condensation

Product Dimensions (LxHxW) (mm/in)

3030.8x1813x31/ 119.3x71.4x1.2

Product Weight (kg/lb)

110/243

Environmental

RoHS
